Your advantages

  • Robust housing in IP65 and IP67
  • Modular construction
  • Ergonomic design
  • Combination of enabling button and operating unit
  • LED diagnosis
  • Increased protection against manipulation thanks to activity sensor
  • Increased protection against manipulation thanks to SSP hand recognition
  • Universal connection with fixed cable

Downloads

ZEUS 01-13 15 30
Enabling/operating unit

​

Zeus Zustimmtaster

Zeus Zustimmtaster mit Handerkennung

ZEUS Zustimmtaster

​

ZEUS guarantees fatigue free activity, thanks to an ergonomical design and low weight. It is suitable for left and right handed persons and easily operated with gloves.
With it's way to function the 3-Step-Enabling Switch ZEUS creates ideal safety conditions in your enabling operation.


Betreff: ZEUS 01-13 15 30 Enabling/operating unit

General data

Item number
1028143
Item number (old)
SP-X-85-902-45
Functional type
Enabling/operating unit

Safety data

Approvals
TÜV, CE

Environmental conditions

Max. storage temperature
-40 ... +80 °C
Max. operating temperature
-5 ... +60 °C
Clearance and creepage distances according to IEC/EN 606641
Overvoltage category: 3 // Contamination level: III

Electrical data

Supply voltage
DC ± 5% 24 V
B10d-value
Enabling button: 100.000

Mechanical data

Enabling button material
Silicon
Base plate
With mounting bracket: only for use with the ZEUS H (SP-X-85-800-00) // screw connections: M20 internal thread
Length
71 mm
Width
69 mm
Height
186 mm
Housing material
PA6.6 30% GF, colour: black
Material for base plate
V2A
Mechanical service life
100.000 switching cycles
Screw torque
0,8 Nm

Drawings

Dimensions
Dimensions

Equipment

MOSAIC M1
S series
S2 series
SP UH-K
X2 series
ZEUS H
ZEUS ZHS
