SAFIX S1

RFID Safety Sensor, lowcoded, autom. reset, M8

SAFIX I1

RFID Safety Sensor, high coded, autom. reset, M8

SAFIX W1

RFID Safety Sensor, high coded (reteach.), autom. reset, M8

SAFIX T3

Standard-actuator for SAFIX 1

SAFIX T4

Flat actuator for SAFIX 1



RFID safety sensors SAFIX 1

Highly coded in small shape- the most modern RFID technology

Up to 80 SAFIXs can be switched in a series, without any significant extension of the reaction time. Therefore it can be integrated in systems with the highest safety level (PLe accordingto ISO 13849-1).
It is obtainable in three different versions, either with high or with low level coding. Due to this, it can provide you with high protection against manipulation, within a compact housing. With an 8-pole M8 connector and OSSD-output signals, the SAFIX can be connected to all kinds of safety relais and is therefore perfectly integrable in any present enviroment. The sensors are combinable with our magnetic locks HOLDX S and HOLDX L, as well as our safe distributerbox XCONN.




SAFIX an einem Werkzeugbahnhof

SAFIX an einem Hubtor




The sensors can be switched in a series, provide detailled LED-diagnosis and are available with different coding levels.


SAFIX's symmetrical shape enables a montage on both sides and is installable without additional angle. The actuator's approach direction is either frontal or lateral. The LED-display is always clearly visible.
Therfore SAFIX can be easily installed at any possible door- it doesn't matter whether it is a sliding, swinging or a folding door.
If SAFIX can be installed in the installation opening, the use of a flat actuator is suggested. Due to it's flat construction, it is adviced to install it especially on flat surfaces, such as doors or screens. The screws used for the montage are either 20mm or 25mm long, depending on the optional use of an additional mounting plate.
